10' x 20' Classic Frame Aluminum Single Tube 10' Pole and Fitting Kit

10' x 20' Classic Frame Aluminum Single Tube 10' Pole and Fitting Kit

The 10' x 20' Classic Frame Aluminum Single Tube 10' Pole and Fitting Kit is a high-clearance structural solution designed for professional applications that require maximum vertical reach. Providing 200 square feet of covered area, this kit is the preferred choice for a rental company tasked with creating high-visibility entrance canopies, elevated production hubs, or weather protection for tall industrial equipment. By utilizing high-strength single-tube aluminum construction, the frame remains lightweight for easy transport while offering the rigidity of a commercial-grade structure. The 10-foot leg height creates a dramatic, airy profile that ensures your setup stands out in any event environment.

This kit serves as a comprehensive hardware foundation for a West Coast Style frame system. Because it adheres to industry-standard dimensions, all components are fully interchangeable with existing West Coast inventories, allowing for simplified maintenance and modular flexibility. The 10-foot leg height is particularly advantageous for tent installation projects where standard-height legs would interfere with tall decor, hanging lighting rigs, or specialized machinery. Whether you are providing a high-profile VIP lounge for a festival or an industrial cover for a localized maintenance project, this single-tube kit offers professional-grade durability with an impressive vertical reach.

Why the 10-Foot Single Tube System Matters

In complex event layouts, height is often a functional necessity for visibility and equipment clearance. The 10' x 20' Classic Frame Aluminum Single Tube 10' Pole and Fitting Kit utilizes 10-foot legs to provide massive overhead clearance, allowing the structure to sit above the heads of a crowd or clear tall obstacles. For a professional event setup, this added height is perfect for installing overhead fans, heaters, or expansive promotional banners. The modular nature of the single-tube aluminum allows for a fast teardown and organized storage, making it a versatile asset for specialized logistics and production teams.

Key Features

• High-Strength Single Tube Aluminum: 2-inch diameter anodized aluminum tubing for a lightweight yet rigid structural frame.
• 10-Foot Eave Height: Specialized leg length provides superior interior clearance and a high-impact profile.
• West Coast Style Compatibility: Fully interchangeable with standard West Coast Style poles, fittings, and vinyl tops.
• Heavy-Duty Welded Steel Fittings: Includes all necessary crowns, side tees, and corners manufactured from zinc-plated steel to resist corrosion.
• Versatile 200 Sq. Ft. Footprint: The industry-standard size for high-visibility kiosks, VIP lounges, and equipment covers.
• Durable Anodized Finish: Aluminum components are treated to maintain a professional appearance through years of frequent outdoor use.

How to Use / Installation Best Practices

Assembling a 10-foot-high frame requires extra caution and a coordinated team to ensure a safe tent installation due to the increased center of gravity.

Step 1: Inventory and Site Layout

Clear the installation area and lay out all rafters, spreaders, and 10-foot legs on a protective drop cloth. Because of the height, verify the ground is level to ensure structural stability during the event setup.

Step 2: Roof Frame Assembly

Assemble the roof framework at ground level by connecting the crowns to the rafters and the perimeter spreaders. Ensure every fitting is secured with R-pins or pin-and-bail fasteners. Double-check all joints, as the 10-foot legs will put more leverage on the roof connections.

Step 3: Vinyl Top Placement

While the frame is still at ground level, pull your 10' x 20' vinyl top over the structure. Centering and securing the top to the perimeter spreaders at this stage is mandatory, as the 10-foot height makes it difficult to adjust the fabric once the legs are raised.

Step 4: Raising the Frame

This step requires a crew of at least four people. Lift one 20-foot side of the frame high enough to insert the 10-foot leg poles into the fittings. While part of the crew steadies the first side, the others should lift the opposite side to insert the remaining legs. Use caution to prevent the legs from kicking out during the lift.

Step 5: Critical Anchoring

Taller structures have a significantly larger wind profile. Immediate stake driving and anchoring with heavy-duty ratchet straps at every leg is required. Tension the straps evenly to ensure the tower remains stable, square, and professional in appearance.

Specifications

• Width: 10 ft (3.0m)
• Length: 20 ft (6.1m)
• Total Area: 200 sq. ft. (18.6 sq. m)
• Leg Height: 10 ft (3.0m)
• Peak Height: 14.5 ft (4.4m)
• Frame Material: 2" Anodized Aluminum Single Tube
• Fitting Material: Zinc-Plated Welded Steel
• Longest Pipe Component: 10 ft (3.0m)
• Approximate Frame Weight: 162 lbs (73.5 kg)
• Compatibility: Standard West Coast Style Frame Systems

Compatibility and Inclusions

This product is a Pole and Fitting Kit ONLY. It is designed for those who already have a compatible 10' x 20' vinyl top and anchoring hardware.

• Included: All aluminum rafters and spreaders, 10-foot aluminum legs, and all required steel fittings (corners, side tees, and crowns).
• NOT Included: Vinyl tent top, anchoring stakes, ratchet straps, and base plates.
• Interchangeability: These parts meet West Coast Style standards and are compatible with most major brands using the same engineering specs.

Ideal for / Best Uses

• High-Visibility VIP Lounges: Perfect for creating an elevated, airy hospitality space at festivals or sporting events.
• Grand Entrance Canopies: Creates a high-clearance, protected path for guests moving into wedding venues or gala halls.
• Camera & Production Platforms: Provides a weather-protected, elevated position for film crews or event photographers.
• Industrial Equipment Protection: A reliable, high-clearance solution for protecting vertical machinery or control panels during maintenance.
