10' x 35' Classic Frame Aluminum Single Tube 12' Pole and Fitting Kit

10' x 35' Classic Frame Aluminum Single Tube 12' Pole and Fitting Kit

The 10' x 35' Classic Frame Aluminum Single Tube 12' Pole and Fitting Kit is an ultra-high-clearance structural solution designed for specialized professional applications that require maximum vertical reach. Providing 350 square feet of covered area, this kit is the premium choice for a rental company tasked with creating dramatic entrance corridors, high-profile VIP walkways, or weather protection for tall industrial equipment. By utilizing high-strength single-tube aluminum construction, the frame remains manageable for transport while offering the rigidity of a commercial-grade system. The massive 12-foot leg height creates an unparalleled airy profile, ensuring your structure stands out as a landmark within any event environment.

This kit serves as a comprehensive hardware foundation for a West Coast Style frame system. Because it adheres to industry-standard dimensions, all components are fully interchangeable with existing West Coast inventories, allowing for simplified maintenance and modular flexibility. The 12-foot leg height is specifically engineered for tent installation projects where standard heights are insufficient—such as clearing tall garden statuary, accommodating large-scale AV production rigs, or sheltering vertical industrial machinery. This single-tube kit offers professional-grade durability with an extraordinary vertical presence.

Why the 12-Foot Single Tube System Matters

In high-density event layouts, extreme height is a functional necessity for visibility, airflow, and clearing overhead obstacles. The 10' x 35' Classic Frame Aluminum Single Tube 12' Pole and Fitting Kit utilizes 12-foot legs to provide massive overhead clearance, preventing any "tunneled" sensation despite the narrow 10-foot width. For a professional event setup, this added height is perfect for suspending complex lighting designs or large-format promotional banners that must be visible from a distance. The modular nature of the aluminum tubing allows for organized teardown and storage, making it a high-utility asset for specialized logistics and production teams.

Key Features

• High-Strength Single Tube Aluminum: 2-inch diameter anodized aluminum tubing for a lightweight yet rigid structural frame.
• 12-Foot Eave Height: Ultra-high leg length provides maximum interior clearance and a towering architectural profile.
• West Coast Style Compatibility: Fully interchangeable with standard West Coast Style poles, fittings, and vinyl tops.
• Heavy-Duty Welded Steel Fittings: Includes all necessary crowns, side tees, and corners manufactured from zinc-plated steel for maximum durability.
• Extended 350 Sq. Ft. Footprint: Designed for high-capacity linear queues, grand walkways, and tall equipment covers.
• Corrosion-Resistant Materials: Anodized aluminum and plated steel are built to withstand repeated outdoor use and moisture.

How to Use / Installation Best Practices

Assembling a 12-foot-high elongated frame requires a large, coordinated crew and strict adherence to safety protocols during the tent installation.

Step 1: Inventory and Site Layout

Clear the 35-foot installation path and lay out all rafters, spreaders, and 12-foot legs on a protective drop cloth. Because of the extreme height, verify the ground is perfectly level to ensure structural stability during the event setup.

Step 2: Roof Frame Assembly

Assemble the roof framework at ground level by connecting the crowns to the rafters and the perimeter spreaders. Ensure every fitting is secured with R-pins or pin-and-bail fasteners. Double-check all joints, as the 12-foot legs will exert significant leverage on the roof connections.

Step 3: Vinyl Top Placement

While the frame is still at ground level, pull your 10' x 35' vinyl top over the structure. Centering and securing the top to the perimeter spreaders at this stage is mandatory; manual adjustments are nearly impossible once the 12-foot legs are raised.

Step 4: Raising the Frame

This step requires a crew of at least six people. Lift one 35-foot side of the frame high enough to insert the 12-foot leg poles into the fittings. While one team steadies the first side, the others must lift the opposite side in unison to insert the remaining legs. Use extreme caution to prevent the legs from kicking out during the lift.

Step 5: Critical Anchoring

Taller structures have a significantly larger wind profile and act as a sail. Immediate stake driving and anchoring with heavy-duty ratchet straps at every leg is required. Tension the straps evenly to ensure the tower remains stable, square, and professional in appearance.

Specifications

• Width: 10 ft (3.0m)
• Length: 35 ft (10.7m)
• Total Area: 350 sq. ft. (32.5 sq. m)
• Leg Height: 12 ft (3.6m)
• Peak Height: 16.5 ft (5.0m)
• Frame Material: 2" Anodized Aluminum Single Tube
• Fitting Material: Zinc-Plated Welded Steel
• Longest Pipe Component: 12 ft (3.6m)
• Approximate Frame Weight: 285 lbs (129.3 kg)
• Compatibility: Standard West Coast Style Frame Systems

Compatibility and Inclusions

This product is a Pole and Fitting Kit ONLY. It is designed for those who already have a compatible 10' x 35' vinyl top and anchoring hardware.

• Included: All aluminum rafters and spreaders, 12-foot aluminum legs, and all required steel fittings (corners, side tees, and crowns).
• NOT Included: Vinyl tent top, anchoring stakes, ratchet straps, and base plates.
• Interchangeability: These parts meet West Coast Style standards and are compatible with most major brands using the same engineering specs.

Ideal for / Best Uses

• Grand Entrance Corridors: Creates a towering, professional path for guests entering high-end wedding venues or galas.
• High-Visibility VIP Walkways: Perfect for creating entrance corridors for festivals that need to be seen from a distance.
• AV & Lighting Support: Provides a durable, high-clearance structure for suspending production equipment over pedestrian paths.
• Tall Industrial Equipment Protection: An ideal solution for protecting vertical machinery, control panels, or silos during maintenance.
