15' x 15' 16 oz. White Pinnacle Series Cross Cable Top

15 x 15 Pinnacle Series Cross Cable Top 16 oz Solid White

The 15 x 15 Pinnacle Series Cross Cable Top 16 oz Solid White is a high-peak frame tent top designed for Pinnacle Series cross cable systems. This 15 x 15 tent top provides 225 square feet of coverage while delivering the signature elevated peak profile that defines upscale event setups. Built for professional rental companies and installation crews, it combines visual impact with efficient tent installation and reliable performance.

Constructed from durable 16 oz blockout PVC coated polyester, this one-piece tent top is engineered for repeated setup, teardown, and transport. The cross cable design supports a high-peak center mast without the need for interior support poles, maximizing usable interior space and improving layout flexibility for events.

Why This Pinnacle Series Cross Cable Top Matters

This 15 x 15 frame tent top is designed for both presentation and performance. The high-peak silhouette elevates the overall look of any event, while the cross cable system eliminates interior obstructions. For rental companies, this means faster setup, better space utilization, and a premium product offering that stands out.

Key Features

• High-peak cross cable design creates an elevated, tensioned roof profile
• 225 sq ft coverage for compact but impactful event setups
• Constructed from 16 oz blockout PVC coated polyester for durability and weather resistance
• No center pole allows for full interior space utilization
• Blockout fabric provides shade and UV protection
• Solid white finish for a clean, professional appearance
• Designed for repeated installation, teardown, and transport

How to Use and Best Practices

Step 1: Assemble the Frame and Cables

Set up the Pinnacle Series frame and install the cross cables between each corner. These cables support the high-peak structure and must be properly tensioned.

Step 2: Position the Tent Top

Drape the one-piece tent top evenly over the frame. Align all corners and ensure the peak is centered over the structure.

Step 3: Attach to Frame

Secure the tent top to the frame at each leg position. Confirm all attachment points are properly connected before tensioning.

Step 4: Raise the Structure

Lift the tent by installing the legs and raising the frame evenly. Ensure the peak forms correctly as the structure rises.

Step 5: Apply Tension and Inspect

Tighten all tension points evenly. Inspect seams, corners, and peak alignment to ensure proper installation and long-term performance.

Specifications

• Product type: Cross cable high-peak tent top
• Tent series: Pinnacle Series
• Size: 15 ft x 15 ft (4.6 m x 4.6 m)
• Coverage area: 225 sq ft (21.2 m2)
• Material: 16 oz PVC coated polyester (540 gsm)
• Fabric type: Blockout, waterproof
• Color: Solid white
• Weight: 52.00 lbs
• Center pole: None (cross cable supported)
• Style: High peak

Compatibility and Important Notes

• Designed specifically for Pinnacle Series cross cable frame systems
• Compatible with 15 ft x 15 ft Pinnacle frames and components
• Requires cross cables and center mast system for proper installation
• This product includes the tent top only
• Frame, cables, mast, ratchets, stakes, and anchoring equipment are not included
• Proper anchoring is required for safe operation

Ideal For

• Weddings and upscale outdoor events
• Corporate activations and branded setups
• Vendor booths and premium display areas
• Event rental companies offering high-peak tent options
• Crews focused on efficient installation and teardown workflows
