2" Box Ratchet w/foot plate

2 Inch Box Ratchet with Foot Plate for Guy Line Tensioning

2 Inch Box Ratchet with Foot Plate is a mechanical tension device used in guy lines to secure a tent, canopy, shelter, or structure to the ground. Built for durability and controlled tensioning, this box ratchet accepts standard 2 inch webbing and provides a stable, ground-mounted anchor point for reliable load management. It is commonly selected for professional event setups and semi-permanent installations where consistent holding strength and repeatable performance are required.

Similar in function to a ratchet buckle assembly, the box ratchet design offers increased sturdiness and controlled operation. The integrated foot plate allows the unit to be staked or anchored directly to the ground, helping crews maintain alignment and tension throughout the installation lifecycle.

Why Box Ratchets Matter

Proper guy line tension is critical to maintaining structural stability, especially in installations exposed to changing loads or environmental conditions. The 2 Inch Box Ratchet with Foot Plate provides a secure, ground-level tensioning solution that helps reduce movement, manage load transfer, and support safer installations over extended periods of use.

Key Features

• Mechanical tension device designed for guy line anchoring
• Accepts standard 2 inch (50.8 mm) webbing
• Operated using a 1 1/8 inch (28.58 mm) socket wrench
• Integrated foot plate for ground staking or anchoring
• Durable construction suited for semi-permanent installations

How to Use the 2 Inch Box Ratchet with Foot Plate

Step 1: Position the Foot Plate

Place the foot plate at the designated anchoring location aligned with the direction of the guy line. Ensure the plate sits flat on the ground for proper load distribution.

Step 2: Anchor the Foot Plate

Secure the foot plate using a compatible stake or concrete anchor through the plate hole. The 1 1/4 inch (31.75 mm) hole is designed to accommodate a standard 1 inch (25.4 mm) stake or concrete anchor.

Step 3: Thread the Webbing

Thread standard 2 inch webbing through the box ratchet according to your installation requirements. Ensure the webbing is aligned and free of twists before tensioning.

Step 4: Apply Tension

Use a 1 1/8 inch socket wrench to turn the bolt and crank the ratchet. Apply steady tension until the guy line is properly secured and the structure is stable.

Step 5: Inspect and Monitor

Inspect the ratchet, webbing, and anchor point to confirm secure engagement. Periodically recheck tension during use, especially in semi-permanent installations or changing weather conditions.

Specifications

• Webbing Compatibility: Accepts 2 inch (50.8 mm) webbing
• Operating Tool: Requires 1 1/8 inch (28.58 mm) socket wrench
• Foot Plate Hole Diameter: 1 1/4 inch (31.75 mm)
• Anchor Compatibility: Standard 1 inch (25.4 mm) stake or concrete anchor

Ideal For

• Guy line tensioning for tents, canopies, and shelters
• Semi-permanent or extended-duration installations
• Event rental companies managing professional setups
• Applications requiring controlled, repeatable tension

Usage Notes

The 2 Inch Box Ratchet with Foot Plate is intended to be used as part of a complete anchoring and tensioning system. Proper stake or anchor selection should be based on soil or surface conditions, expected loads, and installation duration. Always verify compatibility with 2 inch webbing and ensure the correct socket wrench is available for operation. Routine inspection and proper tension management help support safe installations, efficient teardown, and long-term performance in semi-permanent setups.
