40' x 60' Classic Frame Aluminum Double Tube 10' Pole and Fitting Kit

40' x 60' Classic Frame Aluminum Double Tube 10' Pole and Fitting Kit

The 40' x 60' Classic Frame Aluminum Double Tube 10' Pole and Fitting Kit represents the pinnacle of height and structural integrity for professional event shelters. Engineered specifically for the needs of a modern event rental company, this kit provides a massive 2,400-square-foot footprint with an impressive 10-foot eave height. This extra vertical clearance is essential for high-end productions requiring complex lighting rigs, expansive stages, or simply an ultra-grand aesthetic. By utilizing double tube aluminum construction, this 40' x 60' frame delivers the necessary rigidity to support its towering profile, ensuring a stable and secure environment for any large-scale gathering.

This kit is designed as a complete structural solution, featuring the reinforced double-channel aluminum rafters and spreaders required for wide-span West Coast Style tents. Because it follows industry-standard design principles, the components integrate seamlessly with existing inventories of standard fittings and 40x60 vinyl tops. Whether your crew is executing a complex tent installation for a corporate gala or a multi-day festival, this 10-foot leg kit provides the clearance and durability needed to meet the most demanding client specifications while maintaining high safety standards on-site.

Why the 10-Foot Double Tube System Matters

For a structure of this size and height, standard single-tube frames often lack the necessary resistance to wind loads and tension. The 40' x 60' Classic Frame Aluminum Double Tube 10' Pole and Fitting Kit solves this by using structural-grade aluminum with a double-channel profile that significantly increases torque resistance. For an event rental company, the 10-foot height is a major selling point, allowing for better airflow in hot climates and a more luxurious feel. This kit ensures that your event setup is not only visually striking but also engineered to withstand the unique stresses associated with taller perimeter legs.

Key Features

• Ultra-High 10-Foot Eave Height: Provides maximum interior volume, perfect for staging, hanging decor, and improved sightlines.
• Reinforced Double Tube Aluminum: Increases structural stiffness across the 40-foot span, reducing bowing and improving overall stability.
• West Coast Style Compatibility: Standardized design ensures these poles and fittings work with your current West Coast inventory.
• Heavy-Duty Steel Fittings: Includes all necessary welded, zinc-plated steel joints for maximum strength at connection points.
• Corrosion-Resistant Materials: Anodized aluminum and plated steel components are built for longevity and professional appearance.
• Modular Layout: Designed for straightforward assembly and efficient teardown, maximizing crew productivity.

How to Use / Best Practices

Installing a 40' x 60' frame with 10-foot legs requires a coordinated team and specialized attention to anchoring due to the increased wind profile.

Step 1: Layout and Component Check

Organize all rafters, spreaders, and 10-foot legs on a protective drop cloth. Verify that all double tube components are present. This preparation is critical for an efficient tent installation and prevents delays during the lift.

Step 2: Roof Frame Construction

Assemble the ridge and rafters at ground level. Connect the double tube spreaders to form the perimeter. For a 40' x 60' structure, ensure all interior support cables and crown fittings are properly pinned and secured with R-pins or pin-and-bail fasteners.

Step 3: Vinyl Top Placement

Drape the tent top over the frame while it is still low to the ground. Secure the fabric to the frame according to the manufacturer's instructions. Managing the vinyl at this stage is much safer than attempting to adjust it once the 10-foot legs are installed.

Step 4: The 10-Foot Lift

With a large crew (typically 6-10 people), lift one side of the frame and insert the 10-foot leg poles. Because of the extra height, use caution to keep the frame level. Repeat the process for the opposite side until the structure is at full height.

Step 5: Rigorous Anchoring

Due to the 10-foot height, the tent acts as a larger sail in the wind. Immediate stake driving and tensioning with heavy-duty ratchet straps are mandatory. Check all base plates and ensure the structure is plumb and square for maximum stability.

Specifications

• Width: 40 ft (12.2m)
• Length: 60 ft (18.3m)
• Total Area: 2,400 sq ft (223.3 sq m)
• Leg Height: 10 ft (3.05m)
• Peak Height: 20 ft (6.1m)
• Tubing Style: Structural Aluminum Double Tube
• Fitting Material: Zinc-Plated Welded Steel
• Longest Component: 21 ft 10.5 in (6.7m)
• Frame Weight: Approximately 1,770 lbs (803 kg)
• Compatibility: Standard West Coast Style Frame Systems

Compatibility and Inclusions

This product is a Pole and Fitting Kit ONLY. It provides the skeleton of the tent but does not include the fabric or anchoring components.

• Inclusions: All aluminum double-tube poles for rafters/spreaders, 10-foot aluminum legs, and all required steel fittings (crowns, tees, corners).
• Exclusions: Vinyl tent top, anchoring stakes, ratchet straps, and ground cloths are NOT included.
• Requirement: Your tent top MUST be specifically designed for 10-foot leg heights to ensure the valance and side walls fit correctly.

Ideal for / Best Uses

• High-End Weddings: The 10-foot clearance allows for massive floral installations and grand entryways.
• Concert Stages: Provides the necessary height for lighting trusses and elevated performance areas.
• VIP Hospitality Tents: Offers a more open, airy feel that distinguishes premium event spaces from standard rentals.
• Long-Term Maintenance: Durable enough for seasonal installations where maintenance and reliability are paramount.
