7' x 24' Classic Frame Aluminum Single Tube 8' Pole and Fitting Kit

7' x 24' Classic Frame Aluminum Single Tube 8' Pole and Fitting Kit

The 7' x 24' Classic Frame Aluminum Single Tube 8' Pole and Fitting Kit is a specialized structural solution designed for long, narrow configurations. Providing 168 square feet of covered area, this kit is the professional choice for a rental company looking to create sheltered walkways, grand entrance corridors, or narrow food service stations. By utilizing high-strength single-tube aluminum construction, the frame remains lightweight and manageable for rapid deployment, while the 8-foot leg height provides extra vertical clearance for a more open and inviting interior feel.

This kit serves as a comprehensive hardware foundation for a West Coast Style frame system. Because it adheres to industry-standard dimensions, the components are fully interchangeable with existing West Coast inventories, allowing for simplified maintenance and fleet flexibility. The 7-foot width makes it ideal for placement in tight spaces, such as between buildings or along narrow sidewalks, where a standard square tent would not fit. Whether you are providing a weather-protected path for a wedding or an industrial tent installation for a loading dock, this single-tube kit offers professional-grade durability.

Why the 8-Foot Single Tube System Matters

In narrow structures, vertical height is essential to prevent a cramped environment. The 7' x 24' Classic Frame Aluminum Single Tube 8' Pole and Fitting Kit uses 8-foot legs to create a spacious overhead area that accommodates taller guests and decor. For a professional event setup, this creates a clean, elevated canopy that protects against rain or sun without obstructing the flow of traffic. The modular nature of the single-tube aluminum allows for a fast teardown and easy transport, making it a highly efficient asset for busy event schedules.

Key Features

• High-Strength Single Tube Aluminum: Lightweight 2-inch diameter tubing allows for easy handling and reduced labor costs during assembly.
• 8-Foot Eave Height: Increased leg height provides superior clearance for pedestrians and improves overall airflow.
• West Coast Style Compatibility: Fully interchangeable with standard West Coast Style poles, fittings, and vinyl tops.
• Heavy-Duty Welded Steel Fittings: Includes all necessary crowns, side tees, and corners manufactured from zinc-plated steel for maximum durability.
• Corrosion-Resistant Materials: Anodized aluminum and plated steel are designed to withstand repeated outdoor use and moisture.
• Space-Saving 7-Foot Width: Engineered for narrow footprints, walkways, and restricted access areas.

How to Use / Installation Best Practices

Assembling a narrow frame requires attention to alignment to ensure the 24-foot run remains straight and stable during the tent installation.

Step 1: Inventory and Site Layout

Clear the installation path and lay out all rafters, spreaders, and 8-foot legs on a protective drop cloth. Organize the poles by length to ensure a smooth event setup and to prevent confusion during assembly.

Step 2: Roof Frame Assembly

Assemble the roof framework at ground level by connecting the crowns to the rafters and spreaders. For a 24-foot length, verify that every fitting is secured with R-pins or pin-and-bail fasteners to maintain structural integrity.

Step 3: Vinyl Top Placement

While the frame is still low to the ground, pull your vinyl top over the structure. Secure the top to the perimeter spreaders before lifting; this is the safest method to manage the fabric and prevents the wind from catching it during the lift.

Step 4: Raising the Frame

With a small crew, lift one 24-foot side of the frame and insert the 8-foot leg poles into the fittings. Once the first side is stable, repeat the process for the opposite side. Ensure all legs are seated properly in the base plates.

Step 5: Anchoring

Even small frames require secure anchoring to prevent movement. Use stake driving equipment to secure the base of each leg and attach ratchet straps. Tension the straps evenly to ensure the structure is stable and the fabric top is tight.

Specifications

• Width: 7 ft (2.1m)
• Length: 24 ft (7.3m)
• Total Area: 168 sq. ft. (15.6 sq. m)
• Leg Height: 8 ft (2.4m)
• Peak Height: 9.75 ft (3.0m)
• Frame Material: 2" Anodized Aluminum Single Tube
• Fitting Material: Zinc-Plated Welded Steel
• Longest Pipe Component: 7 ft 8 in (2.3m)
• Estimated Frame Weight: 155 lbs (70.3 kg)
• Compatibility: Standard West Coast Style Frame Systems

Compatibility and Inclusions

This product is a Pole and Fitting Kit ONLY. It is designed for those who already have a compatible 7' x 24' vinyl top and anchoring hardware.

• Included: All aluminum rafters and spreaders, 8-foot aluminum legs, and all required steel fittings (corners, tees, and crowns).
• NOT Included: Vinyl tent top, anchoring stakes, ratchet straps, and base plates.
• Interchangeability: These parts meet West Coast Style standards and are compatible with most major brands using the same engineering specs.

Ideal for / Best Uses

• Event Walkways: Provides a professional, covered path for guests moving between venues or from parking areas.
• Entrance Canopies: Creates a grand, 8-foot high entry point for weddings, galas, and corporate events.
• Sidewalk Catering: Ideal for narrow food service setups or bar stations in restricted urban spaces.
• Industrial Access: A durable solution for covering paths between temporary site offices or equipment storage.
