8' x 35' Classic Frame Aluminum Single Tube 8' Pole and Fitting Kit

8' x 35' Classic Frame Aluminum Single Tube 8' Pole and Fitting Kit

The 8' x 35' Classic Frame Aluminum Single Tube 8' Pole and Fitting Kit is a professional-grade structural solution designed for extended, narrow configurations. Providing 280 square feet of covered area, this kit is the industry choice for a rental company looking to create long sheltered walkways, grand entrance corridors, or linear food service stations. By utilizing high-strength single-tube aluminum construction, the frame remains lightweight and manageable for rapid deployment, while the 8-foot leg height provides an open, airy environment that is ideal for high-traffic pedestrian flow and tall equipment.

This kit serves as a comprehensive hardware foundation for a West Coast Style frame system. Because it adheres to industry-standard dimensions, the components are fully interchangeable with existing West Coast inventories, allowing for simplified maintenance and fleet flexibility. The 8-foot width is specifically designed for placement in tight spaces, such as between buildings or along narrow sidewalks, where a standard square tent would be too wide. Whether you are providing a weather-protected path for a wedding or an industrial tent installation for a loading dock, this single-tube kit offers professional-grade durability.

Why the 8-Foot Single Tube System Matters

In narrow configurations, vertical height is essential to prevent a "tunneled" feeling. The 8' x 35' Classic Frame Aluminum Single Tube 8' Pole and Fitting Kit uses 8-foot legs to create a spacious overhead area that accommodates taller guests, lighting, and decor. For a professional event setup, this creates a clean, elevated canopy that protects against rain or sun without obstructing the flow of traffic. The modular nature of the single-tube aluminum allows for a fast teardown and easy transport, making it a highly efficient asset for busy event schedules and industrial sites.

Key Features

• High-Strength Single Tube Aluminum: 2-inch diameter anodized aluminum tubing allows for easy handling and reduced labor costs during assembly.
• 8-Foot Eave Height: Increased leg height provides superior clearance for pedestrians and improved airflow.
• West Coast Style Compatibility: Fully interchangeable with standard West Coast Style poles, fittings, and vinyl tops.
• Heavy-Duty Welded Steel Fittings: Includes all necessary crowns, side tees, and corners manufactured from zinc-plated steel for maximum durability.
• Corrosion-Resistant Materials: Anodized aluminum and plated steel are designed to withstand repeated outdoor use and moisture.
• Space-Saving 8-Foot Width: Engineered for narrow footprints, walkways, and restricted access areas.

How to Use / Installation Best Practices

Assembling a narrow frame requires attention to alignment to ensure the 35-foot run remains straight and stable during the tent installation.

Step 1: Inventory and Site Layout

Clear the installation path and lay out all rafters, spreaders, and 8-foot legs on a protective drop cloth. Organize the poles by length to ensure a smooth event setup and to prevent confusion during assembly.

Step 2: Roof Frame Assembly

Assemble the roof framework at ground level by connecting the crowns to the rafters and spreaders. For a 35-foot length, verify that every fitting is secured with R-pins or pin-and-bail fasteners to maintain structural integrity and prevent the frame from shifting.

Step 3: Vinyl Top Placement

While the frame is still low to the ground, pull your vinyl top over the structure. Secure the top to the perimeter spreaders before lifting; this is the safest method to manage the fabric and prevents the wind from catching it during the lift.

Step 4: Raising the Frame

With a small crew, lift one 35-foot side of the frame and insert the 8-foot leg poles into the fittings. Once the first side is stable, repeat the process for the opposite side. Ensure all legs are seated properly in the base plates.

Step 5: Anchoring

Narrow structures are susceptible to lateral wind forces. Use stake driving equipment to secure the base of each leg and attach heavy-duty ratchet straps. Tension the straps evenly to ensure the structure is stable and the fabric top remains drum-tight.

Specifications

• Width: 8 ft (2.4m)
• Length: 35 ft (10.7m)
• Total Area: 280 sq. ft. (26 sq. m)
• Leg Height: 8 ft (2.4m)
• Peak Height: 10.5 ft (3.2m)
• Frame Material: 2" Anodized Aluminum Single Tube
• Fitting Material: Zinc-Plated Welded Steel
• Longest Pipe Component: 9 ft 4 in (2.8m)
• Estimated Frame Weight: 215 lbs (97.5 kg)
• Compatibility: Standard West Coast Style Frame Systems

Compatibility and Inclusions

This product is a Pole and Fitting Kit ONLY. It is designed for those who already have a compatible 8' x 35' vinyl top and anchoring hardware.

• Included: All aluminum rafters and spreaders, 8-foot aluminum legs, and all required steel fittings (corners, side tees, and crowns).
• NOT Included: Vinyl tent top, anchoring stakes, ratchet straps, and base plates.
• Interchangeability: These parts meet West Coast Style standards and are compatible with most major brands using the same engineering specs.

Ideal for / Best Uses

• Event Walkways: Provides a professional, covered path for guests moving between venues or from parking areas.
• Entrance Canopies: Creates a grand, 8-foot high entry point for weddings, galas, and corporate events.
• Sidewalk Catering: Ideal for narrow food service setups, bar stations, or buffet lines in restricted urban spaces.
• Industrial Access: A durable solution for covering paths between temporary site offices or equipment storage during maintenance.
