1 Way End Rail Fitting

1 Way End Rail Fitting for Classic Frame Tents

The 1 Way End Rail Fitting is a specialized frame tent component designed to support and secure one end of rail or spreader tubing in Classic Frame tent systems. Built for West Coast style frame tents, this fitting is commonly used in rail skirt setups where fabric panels are attached along the perimeter of the tent.

For event rental companies and installation crews, this fitting provides a simple and reliable way to create clean, functional rail systems. It connects directly to tent leg tubing while supporting horizontal rail sections, helping crews maintain consistent alignment and improve the overall appearance of event setups.

Why This End Rail Fitting Matters

Rail systems play an important role in event presentation, especially when using fabric skirts or perimeter coverings. The 1 way end rail fitting ensures that the end of each rail section is properly supported and secured to the tent structure. This improves stability, reduces movement during use, and helps maintain a professional, finished look.

By using a dedicated fitting for end connections, crews can streamline tent installation and avoid makeshift solutions that may compromise alignment or durability.

Key Features

• Designed for West Coast style Classic Frame tent systems
• Supports one end of spreader or rail tubing for rail skirt applications
• Features a single protrusion with standard pin holes for secure connections
• Large opening fits 1.75" to 2.00" diameter leg tubing
• Adjustable height along the leg using an integrated tightening bolt
• Manufactured from 1.25" schedule 40 steel pipe for durability
• Zinc-coated finish helps resist corrosion and wear
• Designed for repeated use in rental and event environments

How to Use and Install

1. Position the Fitting on the Tent Leg

Slide the 1 way end rail fitting onto the tent leg tubing. Move it to the desired height based on your rail or skirt setup.

2. Secure the Fitting in Place

Tighten the built-in bolt to lock the fitting onto the leg tubing. Ensure the fitting is firmly secured before attaching additional components.

3. Attach Rail Tubing

Insert the rail or spreader tubing onto the single protrusion. Align the holes in the tubing with the fitting for proper connection.

4. Insert Pin Fasteners

Secure the connection using pin fasteners through the aligned holes. Ensure all pins are fully inserted to prevent movement during use.

5. Complete Rail Setup

Continue installing additional rail fittings and fabric as needed to complete the rail skirt system. Proceed with standard tent installation and anchoring.

Specifications

• Product Type: 1 way end rail fitting
• Compatibility: West Coast style Classic Frame tent systems
• Material: 1.25" schedule 40 steel pipe
• Finish: Zinc-coated for corrosion resistance
• Leg Tube Compatibility: 1.75" to 2.00" diameter
• Connection Type: Single protrusion with pin holes
• Outside Diameter: 1.656"
• Inside Diameter: 1.38"
• Wall Thickness: 0.14"
• Weight: 3.00 lbs
• Strength: 45,000 PSI
• SKU: F211WERF

Compatibility and Important Notes

• Designed for use with Classic Frame tent systems
• Used specifically for end rail or rail skirt applications
• This is a single component, not a complete frame system
• Pin fasteners are required for installation and may be sold separately
• Ensure compatibility with existing tubing sizes before use

Ideal For

• Event rental companies installing rail skirt systems
• Frame tent perimeter fabric setups
• Replacement or repair of rail support fittings
• Install crews focused on clean and efficient event setups
• Applications requiring secure and adjustable rail connections
