Product Description
7' Medium Duty Al. Pole Bottom
The 7' (2.13 m) Medium Duty Aluminum Pole Bottom is the base used for Medium Duty Center and Quarter Poles. Each pole measures 7' (2.13 m) with a 6" (152.4 mm) swage at the top to connect to the top pole portion. It can also be used as an insert, effectively tripling the pole size. This swage fits into the top pole portion to complete the Medium Duty Pole, compatible with CELINA's 2 3/8" (60.33 mm) O.D. Center Poles. Having sectional, swaged poles eliminates the hassles and dangers associated with transporting long single-piece poles.
This piece is the bottom or center of a medium duty pole:
As a Bottom Pole:
|
| As a Center Pole Insert:
|
Total Height of Pole: 14' (4.27 m), 2 3/8" (60.33 mm) diameter | Total Height of Pole: 21' (6.4 m), 2 3/8" (60.33 mm) diameter |
| Aluminum Pole Specifications | ||
| Outside Diameter | 2.375" | |
| Inside Diameter | 2.0625" | |
| Wall Thickness | 0.156" | |
| Weight | 1.2722 lbs/ft | |
| Strength | 35000 PSI | |
